mW to dBm Conversion Calculator
dBm is a unit of level used to indicate that a power level is expressed in decibels with reference to one milliwatt (1 mW) as a reference point. In order to work with such a wide range of values, optical power is often represented on logarithmic scale as dBm.
Use the calculator to see the correct conversion from mW to dBm.
Enter power in milliwatts or decibel-milliwatts for the calculator conversion.
About Optical Power
Math Formulas
mW to dBm
To convert milliwatts (mW) to decibels-milliwatts (dBm), you can use the following formula:
dBm to mW
To convert decibels-milliwatts (dBm) to milliwatts (mW), you can use the following formula:
Common Conversions
mW to dBm
1 mW is 0 dBm
10 mW is 10 dBm
50 mW is 16.990 dbm
100 mW is 20 dBm
200.000 mW is 23.010 dBm
dBm to mW
0 dBm is 1 mW
1 dBm is 1.259 mW
10 dBm is 10 mW
20 dBm is 100 mW
30 dBm to 1000 mW
W to dBm
1 W is 30 dBm
10 W is 40 dBm
100 W is 50 dBm
1000 W is 60 dBm
10,000 W is 70 dBm
Fiber Optics Calculations
Insertion loss formula
In fiber optics, insertion loss (IL) is the loss of optical power caused by adding a passive component like a patch cord, splitter or WDM in your network. For convenience, decibels (dB) are typically used.
The formula for insertion loss is given by:
