聖威光電 - 產品

622M/2.5G SFF

OPTICAL TRANSCEIVER SFF Optical Transceiver

622M/2.5G SFF

Part Number

SG8525-X3ATXX-WT

SG1325-02ATXX-WT

SG1325-15XXXX-WT

SG1525-40XXXX-WT

SG1325-40XXXX-WT

Quantity

Specification

Part Number	Data Rate	Distance	Wavelength	Connector	Output Power	Sensitivity	Temperature	Remark
SG8525-X3XXXX	2.5G	300m	850nm	LC	-4 to -9 dBm	-15 dBm	0 ~ 70°C
SG8525-X3ATXX-WT	2.5G	300m	850nm	LC	0 to -10 dBm	-16 dBm	-40 ~ 85°C
SG1325-02ATXX	2.5G	2km	1310nm	LC	-3 to -9 dBm	-18 dBm	0 ~ 70°C
SG1325-02ATXX-WT	2.5G	2km	1310nm	LC	-3 to -9 dBm	-18 dBm	-40 ~ 85°C
SG1325-15XXXX	2.5G	15 km	1310nm DFB	LC	0 to -5 dBm	-18 dBm	0 ~ 70°C
SG1325-15XXXX-WT	2.5G	15 km	1310nm DFB	LC	0 to -5 dBm	-18 dBm	-40 ~ 85°C
SG1525-40XXXX	2.5G	40 km	1550nm DFB	LC	3 to -2 dBm	-20 dBm	0 ~ 70°C
SG1525-40XXXX-WT	2.5G	40 km	1550nm DFB	LC	3 to -2 dBm	-20 dBm	-40 ~ 85°C
SG1325-40XXXX	2.5G	40 km	1310nm DFB	LC	3 to -2 dBm	-28 dBm	0 ~ 70°C
SG1325-40XXXX-WT	2.5G	40 km	1310nm DFB	LC	3 to -2 dBm	-28 dBm	-40 ~ 85°C
SG1525-80XXXX	2.5G	80 km	1550nm DFB	LC	3 to -2 dBm	-28 dBm	0 ~ 70°C
