155M 1x9

OPTICAL TRANSCEIVER 1x9 Optical Transceiver

155M 1x9

Part Number

SX8515-02XXXX
SX8515-02XXXX-WT
SX3015-02XXXX
SX3015-02XXXX-WT
SX1315-20XXXX
SX1315-20XXXX-WT
SX1315-30XXXX
SX1315-30XXXX-WT
SX1515-20XXXX
SX1315-40XXXX
SX1315-40XXXX-WT
SX1515-40XXXX
SX1515-40XXXX-WT
SX1515-50XXXX
SX1515-50XXXX-WT
SX1315-60XXXX
SX1315-60XXXX-WT
SX1315-80XXXX
SX1315-80XXXX-WT
SX1515-80XXXX
SX1515-80XXXX-WT
SX1515-00XXXX
SX1515-00XXXX-WT
SX1515-12XXXX
SX1515-12XXXX-WT
SX1515-B0XXXX
SX1515-B0XXXX-WT
SM1315-02XXXX
SM1515-02XXXX-WT
SM1315-20XXXX
SM1315-20XXXX-WT
SM1515-20XXXX
SX1515-20XXXX-WT
SM1315-40XXXX
SM1315-40XXXX-WT
SM1515-40XXXX
SM1515-40XXXX-ET
SM1315-60XXXX
SM1315-60XXXX-WT
SM1515-60XXXX
SM1515-60XXXX-WT
SM1315-80XXXX
SM1315-80XXXX-WT
SM1515-80XXXX
SM1515-80XXXX-WT
SM5115-12XXXX
SM5115-12XXXX-WT
SM5915-12XXXX
SM5915-12XXXX-WT
SM5115-B0XXXX
SM5115-B0XXXX-WT
SM5915-B0XXXX
SM5915-B0XXXX-WT
SC(CWDM)15-80CTXX-ET
SC(CWDM)15-80CTXX-ET

Quantity

Specification

Part Number Data Rate Distance Wavelength Connector Output Power Sensitivity Temperature Remark
SX8515-02XXXX
125/155 M 2km 850nm SC/ST -3 to -10 dBm RX: PIN >0.5 A/W 0 ~ 70°C
SX8515-02XXXX-WT
125/155 M 2km 850nm SC/ST -3 to -10 dBm RX: PIN >0.5 A/W -40 ~ 85°C
SX3015-02XXXX
125/155 M 2km 1310nm SC/FC/ST -12 to -19 dBm -31 dBm 0 ~ 70°C
SX3015-02XXXX-WT
125/155 M 2km 1310nm SC/FC/ST -12 to -19 dBm -31 dBm -40 ~ 85°C
SX1315-20XXXX
125/155 M 20km 1310nm FC -5 to -15 dBm -34 dBm 0 ~ 70°C
SX1315-20XXXX-WT
125/155 M 20km 1310nm ST -2 to -12 dBm -34 dBm -40 ~ 85°C
SX1315-30XXXX
125/155 M 30km 1310nm SC/FC/ST -8 to -15 dBm -34 dBm 0 ~ 70°C
SX1315-30XXXX-WT
125/155 M 30km 1310nm SC/FC/ST -2 to -12 dBm -34 dBm -40 ~ 85°C
SX1515-20XXXX
125/155 M 20km 1550nm SC/ST/FC -8 to -15 dBm -34 dBm 0 ~ 70°C
SX1315-40XXXX
125/155 M 40km 1310nm FC 0 to -5 dBm -34 dBm 0 ~ 70°C
SX1315-40XXXX-WT
125/155 M 40km 1310nm SC/FC/ST 0 to -5 dBm -34 dBm -40 ~ 85°C
SX1515-40XXXX
125/155 M 40km 1550nm SC/ST/FC 0 to -10 dBm -34 dBm 0 ~ 70°C
SX1515-40XXXX-WT
125/155 M 40km 1550nm SC/ST/FC 0 to -10 dBm -34 dBm -20 ~ 85°C
SX1515-50XXXX
125/155 M 50km 1550nm SC/ST/FC 0 to -5 dBm -34 dBm 0 ~ 70°C
SX1515-50XXXX-WT
125/155 M 50km 1550nm SC/ST/FC 0 to -5 dBm -34 dBm -40 ~ 85°C
SX1315-60XXXX
125/155 M 60km 1310nm SC/FC/ST 2 to -4 dBm -36 dBm 0 ~ 70°C
SX1315-60XXXX-WT
125/155 M 60km 1310nm SC/FC/ST 0 to -5 dBm -35 dBm -40 ~ 85°C
SX1315-80XXXX
125/155 M 80km 1310nm SC/FC/ST 5 to 0 dBm -36 dBm 0 ~ 70°C
SX1315-80XXXX-WT
125/155 M 80km 1310nm SC/FC/ST 5 to 0 dBm -36 dBm -40 ~ 85°C
SX1515-80XXXX
125/155 M 80km 1550nm DFB SC/FC/ST 0 to -5 dBm -34 dBm 0 ~ 70°C
SX1515-80XXXX-WT
125/155 M 80km 1550nm DFB SC 0 to -5 dBm -35 dBm -20 ~ 85°C
SX1515-00XXXX
125/155 M 100km 1550nm DFB SC/FC/ST 2 to -3 dBm -36 dBm 0 ~ 70°C
SX1515-00XXXX-WT
125/155 M 100km 1550nm DFB SC/FC/ST 2 to -3 dBm -36 dBm -40 ~ 85°C
SX1515-12XXXX
125/155 M 120km 1550nm DFB SC/FC/ST 5 to 0 dBm -36 dBm 0 ~ 70°C
SX1515-12XXXX-WT
125/155 M 120km 1550nm DFB SC/FC/ST 5 to 0 dBm -36 dBm -40 ~ 85°C
SX1515-B0XXXX
125/155 M 200km 1550nm DFB SC/FC/ST 5 to 2 dBm -45 dBm 0 ~ 70°C
SX1515-B0XXXX-WT
125/155 M 200km 1550nm DFB SC/FC/ST 5 to 2 dBm -45 dBm -40 ~ 85°C
SM1315-02XXXX
125/155 M 2km Tx1310nm / Rx1550nm BiDi SC -8 to -15 dBm -30 dBm 0 ~ 70°C
SM1515-02XXXX-WT
125/155 M 2km Tx1550nm / Rx1310nm BiDi SC -8 to -15 dBm -30 dBm -40 ~ 85°C
SM1315-20XXXX
125/155 M 20km Tx1310nm / Rx1550nm BiDi SC/FC -5 to -15 dBm -32 dBm 0 ~ 70°C
SM1315-20XXXX-WT
125/155 M 20km Tx1310nm / Rx1550nm BiDi SC -8 to -14 dBm -32 dBm -40 ~ 85°C
SM1515-20XXXX
125/155 M 20km Tx1550nm / Rx1310nm BiDi SC -5 to -16 dBm -32 dBm 0 ~ 70°C
SX1515-20XXXX-WT
125/155 M 20km Tx1550nm / Rx1310nm BiDi SC -8 to -14 dBm -32 dBm -40 ~ 85°C
SM1315-40XXXX
125/155 M 40km Tx1310nm / Rx1550nm BiDi SC 0 to -8 dBm -34 dBm 0 ~ 70°C
SM1315-40XXXX-WT
125/155 M 40km Tx1310nm / Rx1550nm BiDi SC 0 to -8 dBm -34 dBm -40 ~ 85°C
SM1515-40XXXX
125/155 M 40km Tx1550nm / Rx1310nm BiDi SC 0 to -8 dBm -34 dBm 0 ~ 70°C
SM1515-40XXXX-ET
125/155 M 40km Tx1550nm / Rx1310nm BiDi SC 0 to -8 dBm -34 dBm -20 ~ 85°C
SM1315-60XXXX
125/155 M 60km Tx1310nm / Rx1550nm BiDi SC 0 to -5 dBm -34 dBm 0 ~ 70°C
SM1315-60XXXX-WT
125/155 M 60km Tx1310nm / Rx1550nm BiDi SC 0 to -5 dBm -34 dBm -40 ~ 85°C
SM1515-60XXXX
125/155 M 60km Tx1550nm / Rx1310nm BiDi SC 1 to -6 dBm -34 dBm 0 ~ 70°C
SM1515-60XXXX-WT
125/155 M 60km Tx1550nm / Rx1310nm BiDi SC 0 to -5 dBm -34 dBm -40 ~ 85°C
SM1315-80XXXX
125/155 M 80km Tx1310nm / Rx1550nm BiDi SC 3 to -2 dBm -35 dBm 0 ~ 70°C
SM1315-80XXXX-WT
125/155 M 80km Tx1310nm / Rx1550nm BiDi SC 3 to -2 dBm -35 dBm -40 ~ 85°C
SM1515-80XXXX
125/155 M 80km Tx1550nm / Rx1310nm BiDi SC 5 to -2 dBm -35 dBm 0 ~ 70°C
SM1515-80XXXX-WT
125/155 M 80km Tx1550nm / Rx1310nm BiDi SC 2 to -3 dBm -35 dBm -40 ~ 85°C
SM5115-12XXXX
125/155 M 120km Tx1510nm / Rx1590nm BiDi SC 3 to -2 dBm -35 dBm 0 ~ 70°C
SM5115-12XXXX-WT
125/155 M 120km Tx1510nm / Rx1590nm BiDi SC 3 to -2 dBm -35 dBm -40 ~ 85°C
SM5915-12XXXX
125/155 M 120km Tx1590nm / Rx1510nm BiDi SC 3 to -2 dBm -35 dBm 0 ~ 70°C
SM5915-12XXXX-WT
125/155 M 120km Tx1590nm / Rx1510nm BiDi SC 3 to -2 dBm -35 dBm -40 ~ 85°C
SM5115-B0XXXX
125/155 M 200km Tx1510nm / Rx1590nm BiDi SC 5 to 1 dBm -45 dBm 0 ~ 70°C
SM5115-B0XXXX-WT
125/155 M 200km Tx1510nm / Rx1590nm BiDi SC 5 to 1 dBm -45 dBm -40 ~ 85°C
SM5915-B0XXXX
125/155 M 200km Tx1590nm / Rx1510nm BiDi SC 5 to 1 dBm -45 dBm 0 ~ 70°C
SM5915-B0XXXX-WT
125/155 M 200km Tx1590nm / Rx1510nm BiDi SC 5 to 1 dBm -45 dBm -40 ~ 85°C
SC(CWDM)15-80CTXX-ET
125/155 M 80km CWDM DFB(1590nm) SC 0 to -6 dBm -34 dBm -10 ~ 85°C
SC(CWDM)15-80CTXX-ET
125/155 M 80km CWDM DFB(1610nm) SC 0 to -6 dBm -34 dBm -10 ~ 85°C
