首頁 / 10G BiDi SFP+

10G BiDi SFP+

OPTICAL TRANSCEIVER SFP+/SFP28 Optical Transceiver

SANOC以優惠的價格提供種類繁多的10G 雙向 SFP+收發器。這些10G雙向模組利用WDM技術，在單根光纖光纜上傳送和接收信號。無論您需要10G BiDi+ SFP 10公里、20公里、40公里、60公里還是80公里的收發器，SANOC都是市場上值得信賴的供應商之一。所有收發器均通過目標交換機的眼圖、誤碼和兼容性測試，確保為您的光纖網絡提供最佳性能。此外，我們提供三年保固、快速出貨，並且對大宗採購提供更多折扣。

Part Number

SS27A0-10ATXX
SS27A0-10ATXX-WT
SS33A0-10ATXX
SS33A0-10ATXX-WT
SS27A0-20ATXX
SS27A0-20ATXX-WT
SS33A0-20ATXX
SS33A0-20ATXX-WT
SS27A0-40ATXX
SS27A0-40ATXX-WT
SS33A0-40ATXX
SS33A0-40ATXX-WT
SS27A0-60ATXX
SS27A0-60ATXX-WT
SS33A0-60ATXX
SS33A0-60ATXX-WT
SS27A0-70ATXX
SS27A0-70ATXX-WT
SS33A0-70ATXX
SS33A0-70ATXX-WT
SS49A0-80ATXX
SS55A0-80ATXX-WT
SS55A0-80ATXX
SS49A0-80ATXX-WT

Quantity

Specification

Part Number Data Rate Distance Wavelength Connector Output Power Sensitivity Temperature Remark
SS27A0-10ATXX
10G 10km Tx1270nm / Rx1330nm BiDi LC DDM 0 to -5 dBm -14 dBm 0 ~ 70°C
SS27A0-10ATXX-WT
10G 10km Tx1270nm / Rx1330nm BiDi LC DDM 0 to -5 dBm -14 dBm -40 ~ 85°C
SS33A0-10ATXX
10G 10km Tx1330nm / Rx1270nm BiDi LC DDM 0 to -5 dBm -14 dBm 0 ~ 70°C
SS33A0-10ATXX-WT
10G 10km Tx1330nm / Rx1270nm BiDi LC DDM 0 to -5 dBm -14 dBm -40 ~ 85°C
SS27A0-20ATXX
10G 20km Tx1270nm / Rx1330nm BiDi LC DDM 3 to -3 dBm -14 dBm 0 ~ 70°C
SS27A0-20ATXX-WT
10G 20km Tx1270nm / Rx1330nm BiDi LC DDM 2 to -2 dBm -14 dBm -40 ~ 85°C
SS33A0-20ATXX
10G 20km Tx1330nm / Rx1270nm BiDi LC DDM 3 to -3 dBm -14 dBm 0 ~ 70°C
SS33A0-20ATXX-WT
10G 20km Tx1330nm / Rx1270nm BiDi LC DDM 2 to -2 dBm -14 dBm -40 ~ 85°C
SS27A0-40ATXX
10G 40km Tx1270nm / Rx1330nm BiDi LC DDM 5 to 1 dBm -15 dBm 0 ~ 70°C
SS27A0-40ATXX-WT
10G 40km Tx1270nm / Rx1330nm BiDi LC DDM 5 to 1 dBm -15 dBm -40 ~ 85°C
SS33A0-40ATXX
10G 40km Tx1330nm / Rx1270nm BiDi LC DDM 5 to 1 dBm -15 dBm 0 ~ 70°C
SS33A0-40ATXX-WT
10G 40km Tx1330nm / Rx1270nm BiDi LC DDM 5 to 1 dBm -15 dBm -40 ~ 85°C
SS27A0-60ATXX
10G 60km Tx1270nm / Rx1330nm BiDi LC DDM 5 to 0 dBm -20 dBm 0 ~ 70°C
SS27A0-60ATXX-WT
10G 60km Tx1270nm / Rx1330nm BiDi LC DDM 7 to 3 dBm -20 dBm -40 ~ 85°C
SS33A0-60ATXX
10G 60km Tx1330nm / Rx1270nm BiDi LC DDM 5 to 0 dBm -20 dBm 0 ~ 70°C
SS33A0-60ATXX-WT
10G 60km Tx1330nm / Rx1270nm BiDi LC DDM 7 to 3 dBm -20 dBm -40 ~ 85°C
SS27A0-70ATXX
10G 70km Tx1270nm / Rx1330nm BiDi LC DDM 9 to 6 dBm -22 dBm 0 ~ 70°C
SS27A0-70ATXX-WT
10G 70km Tx1270nm / Rx1330nm BiDi LC DDM 9 to 6 dBm -22 dBm -40 ~ 85°C
SS33A0-70ATXX
10G 70km Tx1330nm / Rx1270nm BiDi LC DDM 9 to 6 dBm -22 dBm 0 ~ 70°C
SS33A0-70ATXX-WT
10G 70km Tx1330nm / Rx1270nm BiDi LC DDM 9 to 6 dBm -22 dBm -40 ~ 85°C
SS49A0-80ATXX
10G 80km Tx1490nm / Rx1550nm EML BiDi LC DDM 4 to 0 dBm -23 dBm 0 ~ 70°C
SS55A0-80ATXX-WT
10G 80km Tx1490nm / Rx1550nm EML BiDi LC DDM 4 to 0 dBm -23 dBm -40 ~ 85°C
SS55A0-80ATXX
10G 80km Tx1550nm / Rx1490nm EML BiDi LC DDM 4 to 0 dBm -23 dBm 0 ~ 70°C
SS49A0-80ATXX-WT
10G 80km Tx1550nm / Rx1490nm EML BiDi LC DDM 4 to 0 dBm -23 dBm -40 ~ 85°C
