622M SFP

OPTICAL TRANSCEIVER SFP Optical Transceiver

SANOC 622M SFP收發器是針對SONET OC-12、SDH STM-4（622 Mbps）應用的行業標準小型可插拔模組。這些SFP模組符合SFP MSA、CE、FCC、Reach和RoHS標準。我們提供各種適用於不同場景的622M SFP，包括工業和商業網絡。

Part Number

SJ3062-01ATXX-WT

SJ1362-20ATXX-WT

SJ1362-40ATXX-WT

SJ1562-80ATXX-ET

SJ1562-12ATXX-WT

SJ1562-16ATXX-WT

SJ1562-B0ATXX-WT

Quantity

Specification

Part Number	Data Rate	Distance	Wavelength	Connector	Output Power	Sensitivity	Temperature	Remark
SJ3062-01ATXX	622M	1km	1310nm	LC SFP DDM	-12 to -19 dBm	-26 dBm	0 ~ 70°C
SJ3062-01ATXX-WT	622M	1km	1310nm	LC SFP DDM	-12 to -19 dBm	-26 dBm	-40 ~ 85°C
SJ1362-20ATXX	622M	20km	1310nm	LC SFP DDM	-8 to -14 dBm	-28 dBm	0 ~ 70°C
SJ1362-20ATXX-WT	622M	20km	1310nm	LC SFP DDM	-8 to -14 dBm	-28 dBm	-40 ~ 85°C
SJ1362-40ATXX	622M	40km	1310nm	LC SFP DDM	2 to -3 dBm	-28 dBm	0 ~ 70°C
SJ1362-40ATXX-WT	622M	40km	1310nm	LC SFP DDM	2 to -3 dBm	-28 dBm	-40 ~ 85°C
SJ1562-80ATXX	622M	80km	1550nm DFB	LC SFP DDM	2 to -3 dBm	-29 dBm	0 ~ 70°C
SJ1562-80ATXX-ET	622M	80km	1550nm DFB	LC SFP DDM	2 to -3 dBm	-28 dBm	-20 ~ 85°C
SJ1562-12ATXX	622M	120km	1550nm DFB	LC SFP DDM	5 to 0 dBm	-34 dBm	0 ~ 70°C
SJ1562-12ATXX-WT	622M	120km	1550nm DFB	LC SFP DDM	5 to 0 dBm	-34 dBm	-40 ~ 85°C
SJ1562-16ATXX	622M	160km	1550nm DFB	LC SFP DDM	5 to 1 dBm	-37 dBm	0 ~ 70°C
SJ1562-16ATXX-WT	622M	160km	1550nm DFB	LC SFP DDM	5 to 1 dBm	-37 dBm	-40 ~ 85°C
SJ1562-B0ATXX	622M	200km	1550nm DFB	LC SFP DDM	6 to 3 dBm	-37 dBm	0 ~ 70°C
SJ1562-B0ATXX-WT	622M	200km	1550nm DFB	LC SFP DDM	6 to 3 dBm	-37 dBm	-40 ~ 85°C
