首頁 / 1.25G 1x9

1.25G 1x9

OPTICAL TRANSCEIVER 1x9 Optical Transceiver

1.25G 1x9

Part Number

SE8512-X5CPXX
SC8512-X5CTXX-WT
SE8512-X5CPXX-WT
SE8512-X5CTXX-WT
SX1312-10XXXX
SX1312-10XXXX-WT
SX1312-20XXXX
SX1312-20XXXX-WT
SX1312-30XXXX
SX1312-30XXXX-WT
SX1312-40XXXX
SX1312-40XXXX-WT
SX1512-50XXXX
SX1512-50XXXX-WT
SX1512-80XXXX
SX1512-80XXXX-WT
SX1512-12XXXX
SX1512-12XXXX-WT
SX1512-16XXXX
SX1512-16XXXX-WT
SX1512-18XXXX
SC(CWDM)12-80CPXX
SC(CWDM)12-80CPXX
SM1312-X5XXXX
SM1312-X5XXXX-WT
SM1512-X5XXXX
SM1512-X5XXXX-WT
SM1312-10XXXX
SM1312-10XXXX-WT
SM1512-10XXXX
SM1512-10XXXX-WT
SM1312-20XXXX
SM1312-20XXXX-WT
SM1512-20XXXX
SM1512-20XXXX-WT
SM1312-40XXXX
SM1312-40XXXX-WT
SM1512-40XXXX
SM1512-40XXXX-WT
SM1312-60XXXX
SM1312-60XXXX-WT
SM1512-60XXXX
SM1512-60XXXX-ET
SM5112-80XXXX
SM5112-80XXXX-WT
SM5912-80XXXX
SM5912-80XXXX-WT
SM5112-12XXXX
SM5112-12XXXX-WT
SM5912-12XXXX
SM5912-12XXXX-WT

Quantity

Specification

Part Number Data Rate Distance Wavelength Connector Output Power Sensitivity Temperature Remark
SE8512-X5CPXX
1.25G 550m 850nm SC/ST -3 to -9 dBm -20 dBm 0 ~ 70°C
SC8512-X5CTXX-WT
1.25G 550m 850nm SC/ST -3 to -10 dBm -20 dBm -40 ~ 85°C
SE8512-X5CPXX-WT
1.25G 550m 850nm SC/ST -3 to -10 dBm -20 dBm -40 ~ 85°C
SE8512-X5CTXX-WT
1.25G 550m 850nm SC/ST -3 to -10 dBm -20 dBm -40 ~ 85°C
SX1312-10XXXX
1.25G 10km 1310nm SC/FC/ST -3 to -9 dBm -21 dBm 0 ~ 70°C
SX1312-10XXXX-WT
1.25G 10km 1310nm SC/FC/ST -3 to -9 dBm -21 dBm -40 ~ 85°C
SX1312-20XXXX
1.25G 20km 1310nm SC/FC/ST -1 to -6 dBm -22 dBm 0 ~ 70°C
SX1312-20XXXX-WT
1.25G 20km 1310nm SC/ST -3 to -9 dBm -23 dBm -40 ~ 85°C
SX1312-30XXXX
1.25G 30km 1310nm SC/FC/ST 0 to -5 dBm -24 dBm 0 ~ 70°C
SX1312-30XXXX-WT
1.25G 30km 1310nm SC/FC/ST 0 to -5 dBm -24 dBm -40 ~ 85°C
SX1312-40XXXX
1.25G 40km 1310nm SC 3 to -3 dBm -24 dBm 0 ~ 70°C
SX1312-40XXXX-WT
1.25G 40km 1310nm SC/FC/ST 3 to -2 dBm -24 dBm -40 ~ 85°C
SX1512-50XXXX
1.25G 50km 1550nm SC/FC/ST 0 to -5 dBm -24 dBm 0 ~ 70°C
SX1512-50XXXX-WT
1.25G 50km 1550nm SC/FC/ST 0 to -5 dBm -24 dBm -40 ~ 85°C
SX1512-80XXXX
1.25G 80km 1550nm SC/FC/ST 3 to -2 dBm -24 dBm 0 ~ 70°C
SX1512-80XXXX-WT
1.25G 80km 1550nm SC/FC/ST 3 to -2 dBm -24 dBm -40 ~ 85°C
SX1512-12XXXX
1.25G 120km 1550nm SC/FC/ST 5 to 0 dBm -32 dBm 0 ~ 70°C
SX1512-12XXXX-WT
1.25G 120km 1550nm SC/FC/ST 5 to 0 dBm -32 dBm -40 ~ 85°C
SX1512-16XXXX
1.25G 160km 1550nm SC/FC/ST 5 to 2 dBm -34 dBm 0 ~ 70°C
SX1512-16XXXX-WT
1.25G 160km 1550nm SC/FC/ST 5 to 2 dBm -34 dBm -40 ~ 85°C
SX1512-18XXXX
1.25G 180km 1550nm SC/FC/ST 6 to 3 dBm -35 dBm 0 ~ 70°C
SC(CWDM)12-80CPXX
1.25G 80km CWDM DFB(1470nm) SC 5 to 0 dBm -24 dBm 0 ~ 70°C
SC(CWDM)12-80CPXX
1.25G 80km CWDM DFB(1550nm) SC 5 to 0 dBm -24 dBm 0 ~ 70°C
SM1312-X5XXXX
1.25G 550m Tx1310nm / Rx1550nm BiDi SC -4 to -10 dBm -17 dBm 0 ~ 70°C
SM1312-X5XXXX-WT
1.25G 550m Tx1310nm / Rx1550nm BiDi FC 0 to -10 dBm -21 dBm -40 ~ 85°C
SM1512-X5XXXX
1.25G 550m Tx1550nm / Rx1310nm BiDi SC -4 to -10 dBm -17 dBm 0 ~ 70°C
SM1512-X5XXXX-WT
1.25G 550m Tx1550nm / Rx1310nm BiDi SC -4 to -10 dBm -17 dBm -40 ~ 85°C
SM1312-10XXXX
1.25G 10km Tx1310nm / Rx1550nm BiDi SC -3 to -9 dBm -20 dBm 0 ~ 70°C
SM1312-10XXXX-WT
1.25G 10km Tx1310nm / Rx1550nm BiDi SC -3 to -9 dBm -20 dBm -40 ~ 85°C
SM1512-10XXXX
1.25G 10km Tx1550nm / Rx1310nm BiDi SC -3 to -9 dBm -20 dBm 0 ~ 70°C
SM1512-10XXXX-WT
1.25G 10km Tx1550nm / Rx1310nm BiDi SC -3 to -9 dBm -20 dBm -40 ~ 85°C
SM1312-20XXXX
1.25G 20km Tx1310nm / Rx1550nm BiDi SC -3 to -8 dBm -22 dBm 0 ~ 70°C
SM1312-20XXXX-WT
1.25G 20km Tx1310nm / Rx1550nm BiDi SC -2 to -8 dBm -23 dBm -40 ~ 85°C
SM1512-20XXXX
1.25G 20km Tx1550nm / Rx1310nm BiDi SC/FC -3 to -9 dBm -23 dBm 0 ~ 70°C
SM1512-20XXXX-WT
1.25G 20km Tx1550nm / Rx1310nm BiDi SC/FC -2 to -8 dBm -23 dBm -40 ~ 85°C
SM1312-40XXXX
1.25G 40km Tx1310nm / Rx1550nm BiDi SC 2 to -3 dBm -23 dBm 0 ~ 70°C
SM1312-40XXXX-WT
1.25G 40km Tx1310nm / Rx1550nm BiDi SC 2 to -3 dBm -23 dBm -40 ~ 85°C
SM1512-40XXXX
1.25G 40km Tx1550nm / Rx1310nm BiDi FC 0 to -5 dBm -23 dBm 0 ~ 70°C
SM1512-40XXXX-WT
1.25G 40km Tx1550nm / Rx1310nm BiDi SC 2 to -3 dBm -24 dBm -40 ~ 85°C
SM1312-60XXXX
1.25G 60km Tx1310nm / Rx1550nm BiDi SC 4 to 1 dBm -26 dBm 0 ~ 70°C
SM1312-60XXXX-WT
1.25G 60km Tx1310nm / Rx1550nm BiDi SC 5 to 0 dBm -25 dBm -40 ~ 85°C
SM1512-60XXXX
1.25G 60km Tx1550nm / Rx1310nm BiDi SC 2 to -3 dBm -26 dBm 0 ~ 70°C
SM1512-60XXXX-ET
1.25G 60km Tx1550nm / Rx1310nm BiDi SC 4 to -3 dBm -25 dBm -20 ~ 85°C
SM5112-80XXXX
1.25G 80km Tx1510nm / Rx1590nm BiDi SC 3 to -2 dBm -26 dBm 0 ~ 70°C
SM5112-80XXXX-WT
1.25G 80km Tx1510nm / Rx1590nm BiDi SC 3 to -2 dBm -26 dBm -40 ~ 85°C
SM5912-80XXXX
1.25G 80km Tx1590nm / Rx1510nm BiDi SC 3 to -2 dBm -26 dBm 0 ~ 70°C
SM5912-80XXXX-WT
1.25G 80km Tx1590nm / Rx1510nm BiDi SC 3 to -2 dBm -26 dBm -40 ~ 85°C
SM5112-12XXXX
1.25G 120km Tx1510nm / Rx1590nm BiDi SC 2 to -3 dBm -34 dBm 0 ~ 70°C
SM5112-12XXXX-WT
1.25G 120km Tx1510nm / Rx1590nm BiDi SC 2 to -3 dBm -34 dBm -40 ~ 85°C
SM5912-12XXXX
1.25G 120km Tx1590nm / Rx1510nm BiDi SC 2 to -3 dBm -34 dBm 0 ~ 70°C
SM5912-12XXXX-WT
1.25G 120km Tx1590nm / Rx1510nm BiDi SC 2 to -3 dBm -34 dBm -40 ~ 85°C
