0.5M/2M/10M 1x9

OPTICAL TRANSCEIVER 1x9 Optical Transceiver

0.5M/2M/10M 1x9

Part Number

SE8501-02XXXX-WT

SE1301-05XXXX-WT

SE3001-20CTXX-WT

Quantity

Specification

Part Number	Data Rate	Distance	Wavelength	Connector	Output Power	Sensitivity	Temperature	Remark
SE3001-05CTXX	DC~8M	5km	1310nm	ST	-5 to -15 dBm	-34 dBm	0 ~ 70°C
SE1301-20CTXX	DC~8M	20km	1310nm	ST	-3 to -9 dBm	-34 dBm	0 ~ 70°C
SC1301-40CTXX	DC~8M	40km	1310nm	SC/ST	0 to -5 dBm	-24 dBm	-40 ~ 85°C
SE1301-40CTXX	DC~8M	40km	1310nm	SC/ST	0 to -5 dBm	-24 dBm	-40 ~ 85°C
SE8501-02XXXX	DC~10M	2km	850nm	ST	-2 to -9 dBm	-24 dBm	0 ~ 70°C
SE8501-02XXXX-WT	DC~10M	2km	850nm	ST	-2 to -9 dBm	-24 dBm	-40 ~ 85°C
SE1301-05XXXX	DC~10M	5km	1310nm	ST	-5 to -15 dBm	-26 dBm	0 ~ 70°C
SE1301-05XXXX-WT	DC~10M	5km	1310nm	ST	-5 to -15 dBm	-26 dBm	-40 ~ 85°C
SE3001-20CTXX-WT	DC~10M	20km	1310nm	ST	-5 to -15 dBm	-26 dBm	-40 ~ 85°C
SM1301-20APXX	DC~10M	20km	Tx1310nm / Rx1550nm	BiDi SC	0 to -8 dBm	>0.65 A/W	0 ~ 70°C
SM1501-20APXX	DC~10M	20km	Tx1550nm / Rx1310nm	BiDi SC	0 to -8 dBm	>0.65 A/W	0 ~ 70°C
