100BASE SFP

OPTICAL TRANSCEIVER SFP Optical Transceiver

100BASE SFP收發器也稱為100M SFP、155M SFP或FE SFP。它適用於快速以太網交換機和SDH/SONET平台。所有SFP均符合SFF-8472 MSA、CE、FCC和RoHS標準。我們提供各種適用於不同場景的100BASE SFP，包括工業和商業網絡。探索我們的100M SFP模組，立即享受巨大的節省。

Part Number

SJ8515-02ATXX
SJ8515-02ATXX-WT
SJ1315-02ATXX
SJ1315-02ATXX-WT
SJ1315-05ATXX
SJ1315-05ATXX-WT
SJ1315-20ATXX
SJ1315-20ATXX-WT
SJ1315-30ATXX
SJ1315-30ATXX-WT
SJ1315-40ATXX
SJ1315-40ATXX-WT
SJ1315-60ATXX
SJ1315-60ATXX-WT
SJ1515-80ATXX
SJ1515-80ATXX-ET
SJ1515-00ATXX
SJ1515-00ATXX-WT
SJ1515-12ATXX
SJ1515-12ATXX-WT
SJ1515-14ATXX
SJ1515-14ATXX-WT
SJ1515-16ATXX
SJ1515-16ATXX-WT
SJ1515-B0ATXX
SJ1515-B0ATXX-WT

Quantity

Specification

Part Number Data Rate Distance Wavelength Connector Output Power Sensitivity Temperature Remark
SJ8515-02ATXX
125/155 M 2km 850 nm LC SFP DDM -3 to -10 dBm -28 dBm 0 ~ 70°C
SJ8515-02ATXX-WT
125/155 M 2km 850 nm LC SFP DDM -3 to -9dBm -23 dBm -40 ~ 85°C
SJ1315-02ATXX
125/155 M 2km 1310 nm LC SFP DDM -8 to -20 dBm -32 dBm 0 ~ 70°C
SJ1315-02ATXX-WT
125/155 M 2km 1310 nm LC SFP DDM -8 to -20 dBm -32 dBm -40 ~ 85°C
SJ1315-05ATXX
125/155 M 5km 1310 nm LC SFP DDM -6 to -10 dBm -30 dBm 0 ~ 70°C
SJ1315-05ATXX-WT
125/155 M 5km 1310 nm LC SFP DDM -6 to -10 dBm -30 dBm -40 ~ 85°C
SJ1315-20ATXX
125/155 M 20 km 1310 nm LC SFP DDM -5 to -15 dBm -34 dBm 0 ~ 70°C
SJ1315-20ATXX-WT
125/155 M 20 km 1310 nm LC SFP DDM -8 to -15 dBm -32 dBm -40 ~ 85°C
SJ1315-30ATXX
125/155 M 30 km 1310 nm LC SFP DDM -8 to -15 dBm -34 dBm 0 ~ 70°C
SJ1315-30ATXX-WT
125/155 M 30km 1310 nm LC SFP DDM -8 to -13 dBm -34 dBm -40 ~ 85°C
SJ1315-40ATXX
125/155 M 40km 1310 nm LC SFP DDM 0 to -5 dBm -34 dBm 0 ~ 70°C
SJ1315-40ATXX-WT
125/155 M 40km 1310 nm LC SFP DDM 0 to -5 dBm -34 dBm -40 ~ 85°C
SJ1315-60ATXX
125/155 M 60km 1310 nm LC SFP DDM 0 to -5 dBm -34 dBm 0 ~ 70°C
SJ1315-60ATXX-WT
125/155 M 60km 1310 nm LC SFP DDM 0 to -5 dBm -34 dBm -40 ~ 85°C
SJ1515-80ATXX
125/155 M 80 km 1550 nm DFB LC SFP DDM 0 to -6 dBm -34 dBm 0 ~ 70°C
SJ1515-80ATXX-ET
125/155 M 80 km 1550 nm DFB LC SFP DDM 0 to -5 dBm -34 dBm -20 ~ 85°C
SJ1515-00ATXX
125/155 M 100 km 1550 nm DFB LC SFP DDM 0 to -5 dBm -35 dBm 0 ~ 70°C
SJ1515-00ATXX-WT
125/155 M 100 km 1550 nm DFB LC SFP DDM 0 to -5 dBm -35 dBm -40 ~ 85°C
SJ1515-12ATXX
125/155 M 120 km 1550 nm DFB LC SFP DDM 5 to 0 dBm -36 dBm 0 ~ 70°C
SJ1515-12ATXX-WT
125/155 M 120km 1550 nm DFB LC SFP DDM 5 to 0 dBm -34 dBm -40 ~ 85°C
SJ1515-14ATXX
125/155 M 140km 1550 nm DFB LC SFP DDM 6 to 2 dBm -36 dBm 0 ~ 70°C
SJ1515-14ATXX-WT
125/155 M 140km 1550 nm DFB LC SFP DDM 6 to 2 dBm -36 dBm -40 ~ 85°C
SJ1515-16ATXX
125/155 M 160km 1550 nm DFB LC SFP DDM 6 to 2 dBm -38 dBm 0 ~ 70°C
SJ1515-16ATXX-WT
125/155 M 160km 1550 nm DFB LC SFP DDM 6 to 2 dBm -38 dBm -40 ~ 85°C
SJ1515-B0ATXX
125/155 M 200km 1550 nm DFB LC SFP DDM 6 to 2 dBm -44 dBm 0 ~ 70°C
SJ1515-B0ATXX-WT
125/155 M 220km 1550 nm DFB LC SFP DDM 8 to 4 dBm -46 dBm 0 ~ 70°C
